What is a Switch and How is It Used?

One of the basic components of network infrastructures is switch or in Turkish terms switcher, is used in computer networks for the purpose of routing data packets. This routing process is performed based on the MAC address of the devices and ensures a regular distribution of network traffic. However, the increasing communication load within the network and the diversification of requirements further increase the strategic importance of switch use.

The heart of network performance.

Switch devices manage network traffic in the LAN (Local Area Network) quickly and efficiently. This ensures that the data flow on the network is uninterrupted and secure, thereby maximizing performance.

Basic Description of Switch

A switch is a network connection device that allows a large number of devices to share data with each other. Its main function is to control network traffic and route data to the correct destinations. This works as a kind of mail distribution center, allowing incoming data packets to be transmitted to the appropriate ports in the network. Its capabilities, such as routing and filtering of data packets according to address information, have an important role in improving security and performance.

Switches, which act as a central point in network topologies, target maximum efficiency with minimal Deceleration in inter-device communication. These devices, which are used to reduce the complexity in the network and increase the data transmission speed, optimize intra-network traffic by working on the basis of MAC addresses. With these features, switches are one of the indispensable elements of network configurations.

Switch and Hub Differences

Switches are layer 2 (Data Link Layer) devices and are capable of routing data based on MAC addresses. In this way, network traffic is managed effectively and efficiently. Hubs, on the other hand, are layer 1 (Physical Layer) devices and blindly send incoming data to all ports and do not perform traffic management.

While hubs act as simple repeaters, switches intelligently manage the network and forward data to the ports that need it. This improves network performance and security because data leakage to the wrong places is prevented and network load is reduced.

Switches reduce intra-network collisions (collisions) and ensure efficient use of bandwidth.

Hub-connected systems can make a single data transfer at the same time, while switches allow for multiple communication sessions. This allows multiple devices to maintain their own data streams at the same time, significantly reducing congestion in network traffic and minimizing latency. This ability of switches is of critical importance in growing network structures.

Cyber security training and you can visit our website for more information about the effects of these technologies on security practices.

Relationship with the Router

Switch and router they are different network components.

Routers connect different network segments and ensure that data reaches its destination. The switch manages the flow of traffic within a specific network segment, while the router transfers that traffic to different networks or to the Internet, making it part of a larger network. This functional separation allows both devices to play complementary roles in the network environment.

Layer 2 Switch and Layer 3 Router are connected to each other.

The switch improves efficiency on the internal network and the router improves access to external networks. The router’s main task is to deliver data packets between networks to the correct addresses – which is done through IP addressing – whereas the switch facilitates data exchange between devices within the local network based on MAC addressing.

Switches and routers play an important role in network topologies. Routers connect the network to the outside world, usually at the WAN access layer, while switches optimize the flow of data within the LAN and thus play a vital role in increasing the efficiency of the network. This duo is critical in balancing security and performance in complex network structures even in 2024, especially for Cyber Security students.

Types of Switches

Unmanaged Switches: Simple switches that do not require configuration in the network environment. Such devices are designed to automatically forward data packets between network devices via MAC addresses. Unmanaged switches, which are very simple to install and use, are generally preferred in small offices or home networks.

Managed Switches: Devices that provide advanced network management and control. With these switches, network administrators can make detailed configurations such as port-based security settings, creating VLAN (Virtual Local Area Network), setting QoS (Quality of Service) parameters. Their customizable structure according to the requirements of the network is ideal for complex network structures such as ERP (Enterprise Resource Planning) systems.

For more information about the tools used to ensure network security ‘The Best Mobile Pentest Tools 2024‘ read our article.

Manageable Switches

Manageable switches are advanced devices that are at the heart of the network architecture. These devices can be specially configured to ensure network security and efficiency. They are especially indispensable for large and complex networks, because each port can be managed separately.

These devices have the capacity to control the network traffic flow and offer advanced features and fine-tuning. They can be managed with protocols such as SNMP (Simple Network Management Protocol).

Extensibility and customization are the main advantages of manageable switches. As network structures grow and become more complex, these switches allow users to make configurations that suit their specific needs. Thanks to these devices, you can perform operations such as firewall integration, traffic management, network monitoring and troubleshooting.

The manageable switches also support advanced network functions such as QoS, VLAN and per-port security configuration. Thanks to these features, which provide detailed control to network administrators, the network’s security posture is strengthened and system resources are used more effectively. For this reason, manageable switches stand out as a first-class choice, especially for the detection of vulnerable points and the implementation of security measures such as intrusion prevention.

Unmanageable Switches

Unmanaged switches are designed for simple network needs and do not require any configuration. These devices operate on the plug and play principle and, as discovered, they are instantly included in the network. Since there is no management feature, remote access or changes cannot be made by network administrators.

No adjustments are needed on this type of switches. They are simply plugged into the electricity and network connection and work automatically.

It is especially ideal for small offices or home environments. Unmanageable switches are suitable for situations where complex configurations and network management resources are unnecessary.

These devices usually have a lower cost. They offer budget-friendly solutions in simple business networks that do not require advanced network management features.

Unmanageable switch usage does not meet needs such as monitoring or controlling network traffic. Therefore, from the point of view of cyber security practices, the use of these devices offers limited opportunities to increase security.

Unmanageable switches are preferred in installations that do not have a complex network structure and do not require advanced network functions or remote management. These devices, which do not require administrative intervention, provide basic network connectivity with convenience and low cost.

Switch Installation Steps

The installation of the Switch is a fundamental part of creating your network infrastructure. First of all, carefully remove the switch device from its box and select a safe, ventilated and dust-free area for installation. A location where you can easily reach the device’s network ports and power input will be ideal. It is recommended to use an anti-static wristband to protect against static electricity during installation.

Before starting the installation, it is important to check that the firmware version of the switch is up to date. If a new switch has been purchased, manufacturers usually provide firmware updates; installing these updates is critical for the stability and security of the switch. After completing this step, by making your cable connections, you will connect the devices (computers, printers, etc.) you can plug it into your switch. Turn on the device by plugging in the power cord and wait for each of your network devices to be identified and communication on the network to begin.

Cables and Connections

The types of cables used in the switch installation are one of the important factors that can affect the data transmission. As standard, Ethernet cable (such as Cat5, Cat5e, Cat6, Cat6a) is used.

When connecting, it is of great importance that the cables are properly placed and the cable ends are connected to the correct ports. Port and cable incompatibility can lead to serious network performance problems. Therefore, when using twisted pair cable types, the maximum bandwidth and signal quality that it can carry should also be taken into account. In addition, protecting cables from physical damage and managing them in an orderly manner is critical for an efficient network operation.

In order for the switch to coordinate data communication between devices, the port of each device must be correctly identified. Port security and network policies should also be taken into account when making connections based on MAC addresses. This is an effective method to prevent incorrect connections or unauthorized access.

Finally, when it is necessary to send signals over long distances, it may be preferable to use fiber optic cables. The use of fiber optics minimizes potential interference problems and allows high-speed data transmission. However, installing fiber optic cabling can be more complicated due to its cost and technical requirements. At this point, as well as the quality and protection of the cable, it becomes important to use the right types of connectors and understand the distance limitations.

Configuration Settings

It is essential to make the correct configuration settings so that the switches can work effectively and safely. Managing the data flow, network security and performance optimization is one of the basic components of the configuration process.

• Management Interface: The management interface settings provide remote access to the switch and make its management easier.
• Port Configuration: Each port needs a configuration appropriate to its role (for example, VLAN settings).
• Network Security Settings: Security measures such as port security, ACL (Access Control Lists) and DHCP Snooping should be set.
• QoS (Quality of Service): QoS policies are established to regulate data flow and distribute bandwidth fairly.
• STP (Spanning Tree Protocol): STP settings must be made to prevent looping on the network.
• Software/Firmware Updates: Software and firmware updates should be followed regularly in order for the Switch to be up-to-date and secure.

Manageable switches can usually be configured via a web-based interface or CLI (Command Line Interface). These access routes provide detailed configuration options and allow the implementation of complex network configurations.

Finally, redundancy mechanisms need to be defined in switch configurations and the current configuration profile needs to be backed up regularly. This allows the system to be quickly recovered in case of possible malfunctions or configuration errors.

Switch Usage Scenarios

Switches they play a fundamental role in network structure of all sizes, especially in local area networks (LAN) where they are used to efficiently transmit data packets. At the corporate level, network segmentation and trunking it is a key element for increasing network efficiency and preventing broadcast storms thanks to functions such as. Multiport switches, which are also heavily used in the power plants of Internet service providers, serve as a critical building block for users to access the Internet.

Switch configuration according to network topology, VLAN (Virtual Local Area Network) implementation and Layer 2 it meets various needs, such as security measures. Even in home environments, thanks to the integrated switch function on your modem, you can connect multiple devices to the Internet at the same time and manage local network traffic flow.

Improving Network Efficiency

Switches speed up the communication of computers and other devices with the ability to route network traffic, thereby improving overall network efficiency. By being selective in transmitting data packets to the correct destination, they reduce unnecessary traffic on the network.

One of the most effective ways to increase efficiency within the network is to perform network segmentation with switches. This means logically segmenting your network, and each segment processes only its own internal traffic, reducing unnecessary broadcasts and potential network congestion. It also provides great convenience for security and performance management.

Finally, switches optimize network speed by providing bandwidth control on a port by port basis. Bandwidth management supports the fair and efficient use of network resources and thus helps to maintain performance even during times of heavy traffic. Advanced manageable switches provide network administrators with detailed traffic analysis and control, ensuring continuous monitoring of network performance and regulation when necessary.

Their Role in Business

Switches form the backbone of business network structures.

They are vital elements for managing and organizing traffic on an enterprise’s data network. Switches establish communication channels between network devices and ensure the efficient transmission of data packets to the right destinations. This improves network performance and maximizes the speed and security of information exchange. It also reduces the load on the network infrastructure, allowing more efficient use of system resources.

Improves performance by providing the most accurate load distribution.

They are also of central importance in terms of physical security. Switches, thanks to their ability to monitor and manage network traffic, allow detecting suspicious movements on the network and taking measures against these threats with the security protocols they contain. In this way, they offer a comprehensive security base against internal and external threats.

They are one of the cornerstones of data centers. They ensure smooth management of network density and data center operations, support optimal data flow, and help to achieve consistently high business efficiency. The role of switches in the construction and operation of a sustainable network structure has become even more critical by 2024. They assume an important role in gaining a competitive advantage for enterprises by providing all the functions necessary for effective network management and operational efficiency.
